Frost Accumulation Test Apparatus IEC60335-2-24 for Testing Rrefrigerating Compartment

Model PG-FATA

Frost Accumulation Test Apparatus IEC60335-2-24 for Testing Rrefrigerating Compartment

Overview

Frost Accumulation Test Apparatus IEC60335-2-24 for Testing Rrefrigerating Compartment, from Pego Electronics (Yi Chun) Company Limited. The listing gives certification CNAS Calibration Certificate, frame material Bakelite Sheet and thermal conductive material Copper Sheet.

Technical specifications

CertificationCNAS Calibration Certificate
Frame MaterialBakelite Sheet
Thermal Conductive MaterialCopper Sheet
Heating Source5W Incandescent Bulb
Power Regulation200W Voltage Regulator
Copper Plate DimensionΦ60 × 55mm
Weighing MethodDigital Electronic Balance (Customer-Supplied)
Injection MethodManual Injection
Overall DimensionW145mm × D145mm × H145mm
Working Voltage (Input)AC220V/50Hz
Normative StandardIEC60335-2-24 Annex BB And Figure BB.1
Working PowerAC220V/50Hz
Voltage range0~5KV (AC and DC)
Leakage current0~100mA
StandardIEC60335, IEC60598-1, IEC60065 and IEC60950
Test current5~32A/5~70A
Resistance range10.0-200mΩ (32A)/200~600mΩ (10A)
