Overview

Long Working Ceiling Mount Outdoor Motion Sensor Separate Design supplied by Shenzhen HAISEN Technology Co.,Ltd. Listed under Proximity Sensors. Key published specifications: Certification CE RoHS; Operating Frequency 5.8 GHz ±75 MHz; Output DIM 0-10V TTL; Stand-by power <1W. Contact the supplier through the RFQ form for pricing, lead time and full datasheets.

Technical specifications

Certification	CE RoHS
Operating Frequency	5.8 GHz ±75 MHz
Output	DIM 0-10V TTL
Stand-by power	<1W
Operating temperature	-20°C~+55°C
Approval	CE, ROHS
Operating voltage	12 VDC
Operating current	≤25mA
Microwave power	<0.3mW
Mounting Height	Max.15m/49.2ft
Detection range	Max.14m/45.92ft
Daylight threshold	2Lux/10Lux/30Lux/50Lux/80Lux/120Lux/ Disable
Stand-by period	0s/10s/30s/1min/5min/10min/30min/+∞
Hold time	5s/30s/1min/3min/5min/10min/20min/30min
Installation	Installed inside lamps
Life time	50000h
IP rating	IP 20
