Overview

IP65 Bluetooth PIR Motion Sensor Intelligent Movement Detecting supplied by Shenzhen HAISEN Technology Co.,Ltd. Listed under Proximity Sensors. Key published specifications: Operating voltage 120-240VAC 50/60Hz ; 120-277VAC 50/60Hz; Stand-by power ≤1.5W; Hold time 5s/30s/1min/3min/5min/10min/20min/30min; Daylight threshold 2Lux/10Lux/30Lux/50Lux 80Lux/120Lux/Disable. Contact the supplier through the RFQ form for pricing, lead time and full datasheets.

Technical specifications

Operating voltage	120-240VAC 50/60Hz ; 120-277VAC 50/60Hz
Stand-by power	≤1.5W
Hold time	5s/30s/1min/3min/5min/10min/20min/30min
Daylight threshold	2Lux/10Lux/30Lux/50Lux 80Lux/120Lux/Disable
Stand-by period	0s/10s/30s/1min/5min/10min/30min/+∞
Microwave frequency	5.8GHz±75MHz
Microwave power	<0.3mW
Mounting height	Max.15m
Detection range	Max.ø16m
Operating temperature	-35°C~+60°C
IP rating	IP65
Safety standard	EN61347-1 EN61347-2-13 EN60598-1
Life time	50,000 hours
Control Setting	Remote control: HD03R / HD05R ; HAISEN APP
Remote control	HD03R / HD05R ; HAISEN APP
Installation Method (Unit	mm)
