12V DC Low Voltage Photocell Daylight Sensor Brightness Checking supplied by Shenzhen HAISEN Technology Co.,Ltd. Listed under Proximity Sensors. Key published specifications: Operating Voltage 10.5-15V DC; Operating Current 30mA±5%; Microwave Frequency 5.8GHz±75MHz; Stand-by power ≤0.5W. Contact the supplier through the RFQ form for pricing, lead time and full datasheets.

Technical specifications

Operating Voltage	10.5-15V DC
Operating Current	30mA±5%
Microwave Frequency	5.8GHz±75MHz
Stand-by power	≤0.5W
Control Method	1-10V Dimming
Programming	Remote Control
Detection Angle	150° Without Glass Cover
Detection Range	Max.ø14m
Mounting Height	Max.15m
Hold Time	5s/30s/1min/3min/5min/10min/20min/30min
Daylight Threshold	2Lux/10Lux/30Lux/50Lux/80Lux/120Lux/Disable
Stand-by Period	0s/10s/30s/1min/5min/10min/30min/+ ∞
IP Rating	IP65
Operating Temperature	-20°C~+60°C
Max Height	15M
IP Grading	IP65
