Overview

ST505 Ultrasonic Energy Meter with RTD and PT100 supplied by Flo-Instruments Co., Ltd. Listed under Flow Meters. Key published specifications: Keypad 16(4×4) Key With Tactile Action; Temperature Range Transmitter: -40℉~140℉ (-40℃~60℃); Transducer: 32℉~140℉ (0℃~60℃); Velocity Range 0 ~ ±16ft/s (0 ~ ±5m/s); Pipe Size 1”~48”(25mm~1200mm). Contact the supplier through the RFQ form for pricing, lead time and full datasheets.

Technical specifications

Keypad	16(4×4) Key With Tactile Action
Temperature Range	Transmitter: -40℉~140℉ (-40℃~60℃); Transducer: 32℉~140℉ (0℃~60℃)
Velocity Range	0 ~ ±16ft/s (0 ~ ±5m/s)
Pipe Size	1”~48”(25mm~1200mm)
Accuracy	±1% of measured value
Repeatability	0.3% of measured value
Power Supply	24V DC
Display	(20×2) alphanumeric, backlit LCD
Output Type	Specifications
Analog Output	4~20mA, max load 750Ω
Pulse Output	0~9999Hz, OCT (min. and max. frequency adjustable)
Communication	RS485
Component	Specifications
Transmitter	Die-cast aluminum, IP65, CNC machined
Transducer	Encapsulated design, IP68 protection, double-shielded cable
Cable Length	Standard: 30ft (9m), Maximum: 1000ft (305m)
Temperature Range (Transducer)	32℉~140℉ (0℃~60℃) Standard
Humidity	Up to 99% RH, non-condensing
Certification	CE; ISO9001
Standard	30ft (9m), Maximum: 1000ft (305m)
Standard cable length	33ft (10m)
