IP68 Waterproof Load Cell 50kg 20kg 10kg Submersible Force Sensor
Model FSKN
Overview
IP68 Waterproof Load Cell 50kg 20kg 10kg Submersible Force Sensor supplied by Forsentek Co. Limited. Key published specifications: Structure Z-beam Load Cell; Capacity 10kg 20kg 50kg; Force Direction Tension And Compression; Connection M6 Threaded Hole. Contact the supplier through the RFQ form for pricing, lead time and full datasheets.
Technical specifications
| Structure | Z-beam Load Cell |
|---|---|
| Capacity | 10kg 20kg 50kg |
| Force Direction | Tension And Compression |
| Connection | M6 Threaded Hole |
| Ingress Protection | IP68 |
| Rated output | 1.5 mV/V |
| Excitation | 3-12V |
| Zero balance | ±0.1mV/V |
| Nonlinearity | ±0.3% of full capacity |
| Hysteresis | ±0.3% of full capacity |
| Nonrepeatability | ±0.1% of full capacity |
| Creep(3min) | ±0.2% of full capacity |
| Safe overload | 150% of full capacity |
| Ultimate overload | 200% of full capacity |
| Compensated temperature | 0...+40 o C |
| Operating temperature | -20...+60 o C |
| Temperature shift zero | ±0.03% R.O./ o C |
| Temperature shift span | ±0.02% R.O./ o C |
| Input resistance | 380±30 ohms |
| Output resistance | 350±5 ohms |
| Insulation resistance | >2000M ohms |
| Material of element | Stainless steel |
| Cable | Ø3*5000mm 4-core shielded |
| Wiring code @ Tension | Red--Excitation+ Black--Excitation- Green--Signal+ White--Signal- |
