FATS Single Point Load Cell
Overview
FATS Single Point Load Cell supplied by Transcell Intelligent Machinery (Changzhou) Co.Ltd. Key published specifications: Rated Output 2.0mV/V ±10%; Zero Balance ±3% of rated output; Creep after 30 minutes ±0.02% of rated output; Nonlinearity ±0.02% of rated output. Contact the supplier through the RFQ form for pricing, lead time and full datasheets.
Technical specifications
| Rated Output | 2.0mV/V ±10% |
|---|---|
| Zero Balance | ±3% of rated output |
| Creep after 30 minutes | ±0.02% of rated output |
| Nonlinearity | ±0.02% of rated output |
| Hysteresis | ±0.02% of rated output |
| Repeatability | ±0.02% of rated output |
| Temp. effect on output | ≤0.002% of applied output/°C |
| Temp. effect on zero | ≤0.002% of rated output/°C |
| Safe Temp. Range | -10°C to + 70°C |
| Temp. Compensated | -10°C to + 40°C |
| Input Impedance | 410 ohm ± 20 ohm |
| Output Impedance | 350 ohm ± 5 ohm |
| Insulation Resistance | ≥5000 M ohm (50V DC) |
| Rated Excitation | 10V DC/AC |
| Maximum Excitation | 15V DC/AC |
| Cable Length | 45m |
| Cable Color Code | Red(+E) Black(-E) Green(+S) White(-S) |
