High Speed Electrically Insulated Bearings NJ312 ECM/C4VA301 with Brass cage
Model 6310 M/C4VL0241
Overview
CoatMaster Bearings Liaocheng ZhuoYi Bearing Co.,Ltd in Liaocheng, Shandong lists High Speed Electrically Insulated Bearings NJ312 ECM/C4VA301 with Brass cage. The listing gives designation NJ312 ECM/C4VA301, electrical resistance Voltages Up To 3000 V DC and cage Brass.
Technical specifications
| Designation | NJ312 ECM/C4VA301 |
|---|---|
| Electrical Resistance | Voltages Up To 3000 V DC |
| Cage | Brass |
| Cleance | C4 or C3 clearance |
| Dimension | 60×130×31 mm |
| Weight | 2.2 kg |
| Application | Electric Traction Motors |
| Certification | ISO9001 |
| Basic dynamic load rating-C | 173kN |
| Basic static load rating-Co | 160kN |
| Fatigue load limit-Pu | 0 kN |
| Reference speed | 0 r/min |
| Limiting speed | 6700 r/min |
