High Speed 6320 M/C3VL0241 Insulated Rolling Bearing Boundary dimensions
Overview
High Speed 6320 M/C3VL0241 Insulated Rolling Bearing Boundary dimensions supplied by CoatMaster Bearings Liaocheng ZhuoYi Bearing Co.,Ltd. Key published specifications: Designation 6320 M/C3VL0241; Electrical Resistance Voltages Up To 3000 V DC; Cage Brass; Cleance C3 or C4. Contact the supplier through the RFQ form for pricing, lead time and full datasheets.
Technical specifications
| Designation | 6320 M/C3VL0241 |
|---|---|
| Electrical Resistance | Voltages Up To 3000 V DC |
| Cage | Brass |
| Cleance | C3 or C4 |
| Dimension | 100×215×47 mm |
| Weight | 8.1 kg |
| Application | Electric Traction Motors |
| Basic dynamic load rating-C | 174kN |
| Basic static load rating-Co | 140kN |
| Fatigue load limit-Pu | 4.75 kN |
| Reference speed | 6700 r/min |
| Limiting speed | 4300 r/min |
