Flange-Type Pressure Transmitter
Overview
Flange-Type Pressure Transmitter supplied by Wuxi Huihua Special Instrumentation Co., Ltd. Key published specifications: Range 0-0.1MPa...10MPa; Pressure Type Gauge Pressure; Output Signal 4-20mA、0-5V、0-10V; Supply Power 9-24VDC. Contact the supplier through the RFQ form for pricing, lead time and full datasheets.
Technical specifications
| Range | 0-0.1MPa...10MPa |
|---|---|
| Pressure Type | Gauge Pressure |
| Output Signal | 4-20mA、0-5V、0-10V |
| Supply Power | 9-24VDC |
| Accuracy | 0.5%FS |
| Insulation Resistance | 100MΩ/250VDC |
| Zero-point Temperature Drift | 0.5%FS(MAX) |
| Sensitivity Temperature Drift | 0.5FS%(MAX) |
| Pressure Overdrive | ≤1.5Times |
| Mechanical Shock | 20g(20~5000HZ) |
| Sampling Time | 20 Times Per Second |
| Long-term Stability | ≤0.2%FS/Year |
| Level Of Protection | IP65 |
| Medium Compatibility | Various liquid media compatible with 316L stainless steel |
