YSVC-650 (Offline PCB Depanleing Router machine)
Overview
YSVC-650 (Offline PCB Depanleing Router machine), listed under PCB Routers by YUSH Electronic Technology Co.,Ltd in Dongguan, Guangdong. The listing gives system models / types Windows XP Professional, footprint (lxwxh) 800mm*850mm*1700mm and weight (approximate) 150KG.
Technical specifications
| System models / types | Windows XP Professional |
|---|---|
| FootPrint (LxWxH) | 800mm*850mm*1700mm |
| Weight (Approximate) | 150KG |
| Adjustable machine footings (for height) | 60~110mm |
| Manipulator Motor | Panasonic MINAS A5 series |
| Manipulator Repeatability | 0.001mm |
| Maximum Axis Travel (X,Y,Z) | 400mm*650mm*50mm |
| Loading/Unloading | manual |
| Routing Range | 320mm*320mm |
| Panel Thickness | 3mm |
| Rigid Fixturing | Universal thimble & anti-static fixture |
| Top Clamp | Using hole positioning |
| Power | 100W |
| Max. speed | 60000rpm/min |
| Router bit size | 3mm*3mm |
| Tool change | Use Special wrench |
| Max routing speed | 100mm/s |
| Repeatability | 0.02mm |
| Filtration | Vertical and horizontal |
| Air supply | 4~5KG/cm2 |
