YN40 Liquid Filled Pressure Gauge 40MPa 6000PSI Shockproof for Hydraulic Equipment Industrial Use
Model YN40
Overview
YN40 Liquid Filled Pressure Gauge 40MPa 6000PSI Shockproof for Hydraulic Equipment Industrial Use, from Anhui Xingkong Instrument Co., Ltd in Anhui. Published figures include certification CE, ISO, model YN40 and pressure range 0–40MPa / 0–6000 PSI.
Technical specifications
| Certification | CE, ISO |
|---|---|
| Model | YN40 |
| Pressure Range | 0–40MPa / 0–6000 PSI |
| Dial Size | 40mm |
| Case Material | Stainless Steel |
| Wetted Parts | Brass / Copper Alloy |
| Fill Fluid | Glycerin (Liquid Filled) |
| Connection Type | NPT / BSP / G1/4 |
| Mounting Type | Bottom / Back Mount |
| Material | Stainless Steel |
| Liquid Filled | Glycerine |
| Connection | NPT BSP G1/4 |
| Mounting | Bottom / Back |
| Application | Hydraulic Excavator Construction Machinery |
