Vortex Type Aerator Fine Bubble Diffuser Low Energy Consumption High Dynamic Efficiency
Overview
Vortex Type Aerator Fine Bubble Diffuser Low Energy Consumption High Dynamic Efficiency supplied by Jiangsu Ponis Environmental Technologies Co., Ltd. Key published specifications: Certification CE,UL; Oxygenation Capacity 0.112-0.185kgO²/m³/h; Aeration Resistance 180-280mmH₂O; Oxygenation Power Efficiency 4.46-5.19kgO²/kWh. Contact the supplier through the RFQ form for pricing, lead time and full datasheets.
Technical specifications
| Certification | CE,UL |
|---|---|
| Oxygenation Capacity | 0.112-0.185kgO²/m³/h |
| Aeration Resistance | 180-280mmH₂O |
| Oxygenation Power Efficiency | 4.46-5.19kgO²/kWh |
| Total Oxygen Transfer Coefficient | 0.204-0.337min-1 |
| Aerator Dimensions | φ215mm, φ260mm, φ300mm |
| Service Area | 0.25-0.55㎡/unit, 0.35-0.75㎡/unit |
| Average Pore Size | 80-100µm |
| Air Flow Rate | 1.5-3m³/h |
| Average Pore Size of Aeration Membrane | 80-100µm |
