Stator Winding Machine C100
Model C100
Overview
Stator Winding Machine C100, listed under Winding Machines by SMT Intelligent Device Manufacturing (Zhejiang) Co., Ltd in Huzhou, Zhejiang. Published figures include core length 10-90mm, stator i.d 20-80mm and stator o.d ≤140mm.
Technical specifications
| Core Length | 10-90mm |
|---|---|
| Stator I.D | 20-80mm |
| Stator O.D | ≤140mm |
| Height of edge folded | 2-4mm |
| Insulation paper’s thickness | ≤0.35mm |
| Efficiency | 0.5s/s |
| Power supply | 380V, 50/60Hz, 0.75kW |
| Weight | 411kg |
| Dimension | 1100*650*1000mm |
| Automatic Grade | Semiautomatic |
| Indexing Power | Stepper Motor |
| Insulating Material | NMN/DMD/PET |
| Certification | ISO/SGS Audit |
