Nano Microporous Aeration Fine Bubble Tube Diffuser Ultra Fine Bubbles
Overview
Nano Microporous Aeration Fine Bubble Tube Diffuser Ultra Fine Bubbles supplied by Jiangsu Ponis Environmental Technologies Co., Ltd. Key published specifications: Certification CE,UL; Aeration Resistance 180-280mmH₂O; Oxygenation Capacity 0.112-0.185kgO²/m³/h; Air Flow Rate 1.5-3m³/h. Contact the supplier through the RFQ form for pricing, lead time and full datasheets.
Technical specifications
| Certification | CE,UL |
|---|---|
| Aeration Resistance | 180-280mmH₂O |
| Oxygenation Capacity | 0.112-0.185kgO²/m³/h |
| Air Flow Rate | 1.5-3m³/h |
| Service Area | 0.25-0.55㎡/unit, 0.35-0.75㎡/unit |
| Aerator Dimensions | φ215mm, φ260mm, φ300mm |
| Average Pore Size | 80-100µm |
| Total Oxygen Transfer Coefficient | kla (20°C) 0.204-0.337min-1 |
| Oxygenation Power Efficiency | 4.46-5.19kgO²/kWh |
| Average Pore Size of Aeration Membrane | 80-100µm |
