Multi Axis Testing Tension And Compression Load Cell Weighing System
Model F2814
Overview
Multi Axis Testing Tension And Compression Load Cell Weighing System, listed by Shenzhen) Sensors Co., Ltd in Shenzhen, Guangdong. Published figures include structure Compact, material Stainless Steel and capacity 1KN~20KN.
Technical specifications
| Structure | Compact |
|---|---|
| Material | Stainless Steel |
| Capacity | 1KN~20KN |
| Oem/Odm | Acceptable |
| Rated output | 1.5±10%mV/V |
| Zero balance | ±2% F.S. |
| Non-linearity | ≤0.5% F.S. |
| Hysteresis | 0.1% F.S. |
| Repeatability | 0.1% F.S. |
| Creep (30min) | 0.5% F.S. |
| Temp. effect on output | 0.05% F.S. / 10ºC |
| Temp. effect on zero | 0.05% F.S. / 10ºC |
| Insulation | ≥5000MΩ / 50VDC |
| Recommended excitation | 10V |
| Maximum excitation | 15V |
| Compensated temp. range | - 10~60ºC |
| Operation temp. range | - 20~80ºC |
| Safe overload | 150% F.S. |
| Ultimate overload | 200% F.S. |
| Cable size | Ø5*3000 mm |
| Protection class | IP66 |
| Standard | carton |
| Model | F2814 |
| Diameter | 51mm |
| Technical parameters | Specifications |
| Input | Red(+) Black(-); |
| Output | Green(+) White(-); |
