DQ-309H Digital Transmitter
Model DQ-309H-01
Overview
DQ-309H Digital Transmitter supplied by OK Brans Measuring And Controlling Technology Co., Ltd. Key published specifications: Display Type 0.96-inch OLED, Chinese/English Selectable; Display Digits Max. Display Range 200,000 (6 Digits); Housing Material ABS Flame-retardant Material; Dimension(L*W*H) 90mm × 84mm × 42mm. Contact the supplier through the RFQ form for pricing, lead time and full datasheets.
Technical specifications
| Display Type | 0.96-inch OLED, Chinese/English Selectable |
|---|---|
| Display Digits | Max. Display Range 200,000 (6 Digits) |
| Housing Material | ABS Flame-retardant Material |
| Dimension(L*W*H) | 90mm × 84mm × 42mm |
| Input Load (Number of Sensors) | 4–6 pcs of 350Ω sensors |
| Communication Interface | Ethernet, RS232, RS485 |
| Communication Protocol | MODBUS-RTU, MODBUS-TCP |
| Display | 0.96-inch OLED, Chinese/English selectable |
| Display Resolution | Maximum display range: 200,000 |
| Power Supply | 24VDC ±1%, power consumption ≤10W |
| Function Keys | 4 membrane keys |
| Dimensions (L × W × H) | 90mm × 84mm × 42mm |
| Number of Channels | Supports up to 6 independent ADC channels |
| Protection Class | IP20 |
| Operating temperature | -10°C to 40°C; humidity: 10%–95% non-condensing |
| Dimensions | 90mm×84mm×42mm; ABS flame-retardant housing; IP20 protection |
| Temperature | -10°C ~ 40°C (-14°F ~ 104°F); |
| Relative humidity | 10% ~ 95%, non-condensing |
