Chemical Sludge Rotary Disk Filter Pre Treatment Equipment For Wastewater
Overview
Chemical Sludge Rotary Disk Filter Pre Treatment Equipment For Wastewater, from Jiangsu Ponis Environmental Technologies Co., Ltd in Yixing, Jiangsu. The listing gives certification CE,UL, filtration rate 8-15m/h/m2 and processing flow 28~35m3/h (single Disk).
Technical specifications
| Certification | CE,UL |
|---|---|
| Filtration Rate | 8-15m/h/m2 |
| Processing Flow | 28~35m3/h (single Disk) |
| Influent Water Quality | SS≤30mg/L |
| Control Method | Fully Automatic |
| Filter plate diameter | 2000mm |
| Filtration area | 4.5m²/single disc |
| Outlet water quality | SS≤10mg/L |
| Filter disc material | Reinforced engineering plastic |
| Filter cloth material | Stainless steel, PE polyester |
| Body material | Stainless steel |
| Cleaning pressure | 6-8 bar |
| Backwash pump power | 5-11KW |
| Head loss | 50-200mm |
| Backwash drive power | 1.5KW |
