Bending Beam Load Cell WL-122 0.017% Error 50-1000kg Stainless Steel IP67
Model WL-122
Overview
Bending Beam Load Cell WL-122 0.017% Error 50-1000kg Stainless Steel IP67 supplied by OK Brans Measuring And Controlling Technology Co., Ltd. Key published specifications: Material Stainless Steel; Capacity 50/100/200/300/500/600kg; Rated Output 2.0±0.002mV/V; Combined Error 0.017%F.S.. Contact the supplier through the RFQ form for pricing, lead time and full datasheets.
Technical specifications
| Material | Stainless Steel |
|---|---|
| Capacity | 50/100/200/300/500/600kg |
| Rated Output | 2.0±0.002mV/V |
| Combined Error | 0.017%F.S. |
| Recommended Excitation | 5~15VDC |
| Cable | Ф6x3000mm(Customizable) |
| Safe Overload | 120%F.S |
| Protection | IP68 (Customizable) |
| Platform Max | 800×1000mm |
| Non-linearity | 0.017%F.S. |
| Repeatability | 0.01%F.S. |
| Zero Balance | <1%mV/V |
| Insulation Resistance | >5000M Ω /100VDC |
| Operation temp | -40~65°C |
| IP class | IP68 (Customizable) |
| Cable size | Ф6.3x2500mm(Customizable) |
| Certification | CNAS |
