130KW High-Efficiency Double Arbor Rip Saw for Large Wood Planks Processing

Model ZDP600

130KW High-Efficiency Double Arbor Rip Saw for Large Wood Planks Processing

Overview

130KW High-Efficiency Double Arbor Rip Saw for Large Wood Planks Processing supplied by Weifang Jiuyi Information technology co., LTD. Listed under Sawmill Machinery. Key published specifications: Certification ISO9001; Motor Power Of Bottom Arbor 75KW; Motor Power Of Top Arbor 55kw; Diameter Of Circular Saws 455mm. Contact the supplier through the RFQ form for pricing, lead time and full datasheets.

Technical specifications

CertificationISO9001
Motor Power Of Bottom Arbor75KW
Motor Power Of Top Arbor55kw
Diameter Of Circular Saws455mm
Max. Infeed Width600mm
Max. Sawing Thickness300mm
Feeding TypeAuto Feeding
Guarantee1 Year
ModelZDP600
Sawing height /thickness100-300mm
Main motor power, bottom arbor75KW
Main motor power, top arbor55KW
Carbide circular blade up/down3sets (6pcs) with the machine
Feeding speedFrequency speed adjustable
Number of feeding rollers3 pcs top ; 6pcs bottom
Weight4300kgs
Voltage380V / 50Hz / 3 phase
Max. sawing width350 or 400mm
Max. sawing height120mm
Min sawing length600mm
Main Motor power37kw x2
Saw blade diameter255mm
Main shaft diameter70mm
Machine weight2450kg
45kw&55kw55kw x2
Dual-Arbor Configuration75KW (bottom) / 55KW (top)
Sawing Thickness300mm (Massive capacity)
