Zoli Planetary Ball Mill with 500ml Capacity & 0.1 Micron Granularity
Model XQM-0.4
Overview
Zoli Planetary Ball Mill with 500ml Capacity & 0.1 Micron Granularity supplied by Guangzhou Zoli Technology Co.,Ltd. Key published specifications: Volume of each matched Jar 100ml; Voltage 220V - 50Hz; Machine Size 500*300*340mm; Machine Weight 100 Kg without mill jar. Contact the supplier through the RFQ form for pricing, lead time and full datasheets.
Technical specifications
| Volume of each matched Jar | 100ml |
|---|---|
| Voltage | 220V - 50Hz |
| Machine Size | 500*300*340mm |
| Machine Weight | 100 Kg without mill jar |
| Work mode | 4 jars working together |
| Mill mode | Dry / wet milling |
| Speed Frequency | Adjusting |
| Drive Mode | Gear drive |
| Rotational Speed | 90-870 r/min, adjusting |
| Material Capacity | Material + mill balls < 2/3 volume |
| Output Granularity Size | Minimum 0.1μm |
| Max. continuous operating time (full-load) | 72 hours |
| Interval operation | With direction reversal |
| Vertical Ceramic Nano-Scale Mill | ZOLI Ball Mill |
| Scale | Small (Bench-Top) |
| Small (Bench-Top) | Determined by specifications |
| Mechanism | Planetary |
| Orientation | Vertical or Horizontal |
| Vertical | Determined by specifications |
| Primary Use | General Lab Grinding/Mixing |
| Nano-Powders, Ceramics | Determined by specifications |
| Grinding Media | Various (SS, Nylon, etc.) |
| Ceramic (ZrO₂, Al₂O₃) | Determined by specifications |
| Type of Term | General Category |
| Specific Application & Design | Brand/Model Name |
| Certification | ISO CE |
| Max Capacity | 500ml |
| Grinding Ball Diameter | 3mm, 5mm, 10mm |
