Wafer Type Segment Ball Valves
Overview
Wafer Type Segment Ball Valves supplied by Vcore Valve co., Ltd. Key published specifications: Size Range DN25 – DN250 (NPS 1″ – 10″); Pressure Rating PN16/PN25/PN40; Class 150/300; Body Material Stainless Steel (304/316), Carbon Steel (WCB); Seat Material PTFE, RTFE, PEEK, Metal-to-Metal. Contact the supplier through the RFQ form for pricing, lead time and full datasheets.
Technical specifications
| Size Range | DN25 – DN250 (NPS 1″ – 10″) |
|---|---|
| Pressure Rating | PN16/PN25/PN40; Class 150/300 |
| Body Material | Stainless Steel (304/316), Carbon Steel (WCB) |
| Seat Material | PTFE, RTFE, PEEK, Metal-to-Metal |
| Connection Type | Wafer (between flanges, ASME B16.5 / EN 1092-1) |
| Flow Characteristic | Equal Percentage / Linear |
| Certifications | ISO 9001, CE, API 6D, ASME B16.10 |
| Common Applications | Pulp & Paper |
