PNP Capacitive Sensor , IP66 Precise Capacitive Liquid Level Sensor
Model YW15N/YW30N
Overview
PNP Capacitive Sensor , IP66 Precise Capacitive Liquid Level Sensor supplied by Guangdong Boyijingke Sensing Co., Ltd. Listed under Photoelectric Sensors. Key published specifications: Document liquid level sensor-1.pdf; Theory Capacitive Detection Principle; Voltage - Supply 10-30V; Material ABS. Contact the supplier through the RFQ form for pricing, lead time and full datasheets.
Technical specifications
| Document | liquid level sensor-1.pdf |
|---|---|
| Theory | Capacitive Detection Principle |
| Voltage - Supply | 10-30V |
| Material | ABS |
| Function | Liquid level detection control |
| Detectable Objects | liquid |
| Repeat Accuracy | <0.2mm |
| Sensitivity Adjustment | knob adjustment |
| Response Frequecy | 20Hz |
| Output Mode | NPN open collector |
| Switch Mode | Normal open |
| Working Voltage | DC 10~30V ±10% |
| Residual Voltage (Voltage Drop) | <1V |
| Consumption (no-load) Current | <12mA |
| Protection Level | IP66 |
| Connection Type | cable-type (3 core, 2 meter standard cable) |
| Housing Material | ABS |
| Insulation resistance | above 20MΩ (DC 500V megohmmeter) |
| Applicable Piple Outerdiameter | Within 0~15mm |
| working humidity | 35%~85% RH |
| Mounting type | Non Flush |
| Power supply | DC 10~30V |
| Pipe wall thickness | less than 1mm |
| Sensing range | 8mm |
