Laser Marking Machine CO2-D200
Overview
Laser Marking Machine CO2-D200 supplied by Laser Corporation. Listed under Laser Marking Machines. Key published specifications: Laser Type CO2 Laser; Wavelength 10.6 µm (nominal); Min Beam Diameter < 100 µm; Pulse Width Adjustment Ranges 4ns, 8ns, 14ns, 20ns, 30ns,50ns, 100ns, 200ns. Contact the supplier through the RFQ form for pricing, lead time and full datasheets.
Technical specifications
| Laser Type | CO2 Laser |
|---|---|
| Wavelength | 10.6 µm (nominal) |
| Min Beam Diameter | < 100 µm |
| Pulse Width Adjustment Ranges | 4ns, 8ns, 14ns, 20ns, 30ns,50ns, 100ns, 200ns |
| Pulse Frequency | 20 – 100 kHz |
| Output Power | 200 Watts |
| Repetition Accuracy | ± 0.0004” (0.01mm) |
| Cooling System | Fully Water Cooled |
| Operation System | WINDOWS 7 or 10 |
| Power Consumed | 4kW |
| Weight (unpacked) | 220 lbs （100kg） |
| Warranty Coverage | 1-year |
| Laser Safety Compliance | FDA(CDRH) |
| Running Temperature | 15℃-35℃ / 59°-95°F |
