Hydraulic Stone Cutter
Overview
Hydraulic Stone Cutter supplied by YG Machinery. Listed under Excavators. Key published specifications: Wire Drive Mode hydraulic; Rated Output Power 22/25KW; Model Type HM-40/80; Working Voltage 380v 50Hz. Contact the supplier through the RFQ form for pricing, lead time and full datasheets.
Technical specifications
| Wire Drive Mode | hydraulic |
|---|---|
| Rated Output Power | 22/25KW |
| Model Type | HM-40/80 |
| Working Voltage | 380v 50Hz |
| Minimum Input Power | 25HP/33HP |
| Hydraulic Pump Station | Gear pump |
| Output Shaft Speed | 350/940/1300r/min |
| Motor Working Floe | 40-100L/min |
| Maximum Wire Length | 18m |
| Working Pressure | 15-20Mpa |
| Feeding Method | Fully hydraulic |
| Oil Tank Volume | 16L |
| Wire Saw Wheel | 64kg |
| Weight | 98kg |
| Motor Weight | 13kg |
