Final Drive PHV-1B
Model PHV-1B
Overview
Final Drive PHV-1B supplied by WEITAI. Key published specifications: Frame flange orientation diameter 140mm; Frame flange bolt pattern 8-M10; Frame flange holes P.C.D. 155mm; Sprocket flange orientation diameter 140mm. Contact the supplier through the RFQ form for pricing, lead time and full datasheets.
Technical specifications
| Frame flange orientation diameter | 140mm |
|---|---|
| Frame flange bolt pattern | 8-M10 |
| Frame flange holes P.C.D. | 155mm |
| Sprocket flange orientation diameter | 140mm |
| Sprocket flange bolt pattern | 9-M10 Equally |
| Sprocket flange holes P.C.D. | 155mm |
| Flange distance | 45mm |
| Approximate weigth | 20kg (44lbs) |
