Energy Saving 1.5KW Rotary Disc Filter Continuous Operation with Auto Cleaning
Overview
Energy Saving 1.5KW Rotary Disc Filter Continuous Operation with Auto Cleaning supplied by Jiangsu Ponis Environmental Technologies Co., Ltd. Key published specifications: Certification CE,UL; Body Material Stainless Steel; Backwash Drive Power 1.5KW; Backwash Pump Power 5-11KW. Contact the supplier through the RFQ form for pricing, lead time and full datasheets.
Technical specifications
| Certification | CE,UL |
|---|---|
| Body Material | Stainless Steel |
| Backwash Drive Power | 1.5KW |
| Backwash Pump Power | 5-11KW |
| Processing Flow | 28~35m3/h (single Disk) |
| Influent Water Quality | SS≤30mg/L |
| Filter plate diameter | 2000mm |
| Filtration area | 4.5m²/single disc |
| Filtration rate | 8-15m/h/m² |
| Outlet water quality | SS≤10mg/L |
| Filter disc material | Reinforced engineering plastic |
| Filter cloth material | Stainless steel, PE polyester |
| Washing water volume | 30L/1 tray/1 time |
| Cleaning pressure | 6-8 bar |
| Head loss | 50-200mm |
| Backwash cycle | 1-3min (or continuous) |
