Cabinet marking machine
Overview
Cabinet marking machine supplied by Liaocheng Development Zone Jingke Laser Equipment Co., Ltd. Listed under Lasers. Key published specifications: Laser power (Power) 10W/20W/30W/50W/100W; Fiber Source MAX/RAYCUS/IPG; Beam quality M2<1.5; Marking Speed ≤12000mm/s. Contact the supplier through the RFQ form for pricing, lead time and full datasheets.
Technical specifications
| Laser power (Power) | 10W/20W/30W/50W/100W |
|---|---|
| Fiber Source | MAX/RAYCUS/IPG |
| Beam quality | M2<1.5 |
| Marking Speed | ≤12000mm/s |
| Minimum character height | 0.05mm |
| Cooling Mode | Air cooled or water cooled |
| Repeated precision | ±0.001mm |
| Marking area (carving area) | 70*70/150*150/200*200/ 300*300mmOptional |
| Power Requirement | 220v/50hz |
| Minimum line width (minimum line width) | 0.012mm |
| Minimum character (minimum character) | 0.15mm |
| cooling method (cooling method) | Air cooled or water cooled |
| Main parts | Fiber Source |
| Marking software (marking software) | EZCAD |
| Total Power | ≤500W |
| Applicable Materials (applicable materials) | Metal and part of non-metal |
| Location (location) | Dynamic tagging and static tagging |
