wood engraving machine
Overview
wood engraving machine supplied by Liaocheng Development Zone Jingke Laser Equipment Co., Ltd. Listed under Lasers. Key published specifications: Laser type (laser type) CO2; Laser power 50W/60W/80W/100W; Working area (L*W) (work area) 600mm*400mm; Engraving speed 1----1200mm/S. Contact the supplier through the RFQ form for pricing, lead time and full datasheets.
Technical specifications
| Laser type (laser type) | CO2 |
|---|---|
| Laser power | 50W/60W/80W/100W |
| Working area (L*W) (work area) | 600mm*400mm |
| Engraving speed | 1----1200mm/S |
| Cutting speed(Cutting speed) | 1---1200mm/S |
| Working Voltage | 110v + 10% 50HZ/220v + 10% 60HZ |
| Minimum Character | Engling 1mm 2mmof chinese characters |
| Guideway (guide) | High precision linear square rail |
| Drive Mode (drive mode) | Digital subdivision stepper diiver |
| Positioning Mode (Positioning mode) | Red light positioning |
| Compatible Software (Compatible Software) | Artuct/photoshop/coreldraw/autoCAD/lasercut |
| Applicable Material (cutting material) | Non-metallic material |
| Cooling Mode (Cooling Mode) | Water cooling |
| Control Software (Control Software) | DSP |
| Optional Device (Optional Device) | Rotary device |
| Highest Scanning Precision | 0.01MM |
| Color Separation (color separation) | yes |
| Control software language | English/ Chinese |
| Working material | Non-metallic material |
| Net weight(Net weight) | 90KG |
| Gross weight | 120KG |
| working table | Strip work table(Optional honeycomb, blade) |
| Laser head | High precision closed |
| USB Ports | USB2.0 |
| Protection System | Water protection |
| Warranty(Warranty) | 2 YEARS |
| Machine size | 1400*790*580mm |
| Transmission (Transfer) | Nylon belt |
| Controller Brand | Ruida AWC |
