Wheel Hub 515095

Wheel Hub 515095

Overview

Wheel Hub 515095, from DUHUI Bearing. Dh code DWH1590, product type Wheel Bearing & Hub Assembly and installation location Front Axle are among the specifications published.

Technical specifications

DH CodeDWH1590
Product TypeWheel Bearing & Hub Assembly
Installation LocationFront Axle
Kit ContentsHub × 1
Flange Diameter7.205″ / 183.00 mm
Flange Offset1.811″ / 46.00 mm
Bolt Circle Diameter5.315″ / 135.00 mm
Hub Pilot Diameter3.911″ / 99.30 mm
Wheel Pilot Diameter3.422″ / 86.80 mm
Brake Pilot Diameter3.543″ / 90.00 mm
Bolt SizeM14 × 2
Flange ShapeModified / Rectangular
ABS SensorWith integrated sensor ring
