Wheel Hub 515007

Wheel Hub 515007

Overview

Wheel Hub 515007, listed by DUHUI Bearing. Dh code DWH1503, product type Wheel Hub Assembly and installation location Front Axle are among the specifications published.

Technical specifications

DH CodeDWH1503
Product TypeWheel Hub Assembly
Installation LocationFront Axle
Kit ContentsHub × 1
Flange Diameter160.30 mm (6.310 inch)
Bolt Circle Diameter114.30 mm (4.500 inch)
Wheel Pilot Diameter71.40 mm (2.812 inch)
Brake Pilot Diameter73.40 mm (2.890 inch)
Flange Offset53.50 mm (2.106 inch)
Hub Pilot Diameter88.90 mm (3.500 inch)
Hub Bolt Circle Diameter124.50 mm (4.900 inch)
Bolt SizeM14 × 1.5
Bolt Hole METM14 × 1.5
Flange ShapeTriangular
ABS SensorWithout sensor (Non-ABS)
