Wheel Hub 513121

Wheel Hub 513121

Overview

Wheel Hub 513121, listed by DUHUI Bearing. Dh code DWH01349, product type Wheel Hub Assembly and installation location Front & Rear Axle are among the specifications published.

Technical specifications

DH CodeDWH01349
Product TypeWheel Hub Assembly
Installation LocationFront & Rear Axle
Kit ContentsHub × 1
Flange Diameter5.728″ / 145.50 mm
Bolt Circle Diameter4.528″ / 115.00 mm
Wheel Pilot Diameter2.756″ / 70.00 mm
Brake Pilot Diameter2.756″ / 70.00 mm
Flange Offset2.736″ / 69.50 mm
Hub Pilot Diameter3.598″ / 91.40 mm
Hub Bolt Circle Diameter4.567″ / 116.00 mm
Bolt SizeM12 × 1.5
Bolt Hole METM12 × 1.75
Flange ShapeModified Triangle
