Overview

Wheel Hub 512340 supplied by DUHUI Bearing. Listed under Roller Bearings. Key published specifications: DH Code DWH1232; Product Type Wheel Hub Assembly; Installation Location Rear Axle; Kit Contents Hub × 1. Contact the supplier through the RFQ form for pricing, lead time and full datasheets.

Technical specifications

DH Code	DWH1232
Product Type	Wheel Hub Assembly
Installation Location	Rear Axle
Kit Contents	Hub × 1
Flange Diameter	5.827″ / 148.00 mm
Bolt Circle Diameter	4.500″ / 114.30 mm
Wheel Pilot Diameter	2.638″ / 67.00 mm
Brake Pilot Diameter	2.992″ / 76.00 mm
Flange Offset	2.323″ / 59.00 mm
Hub Pilot Diameter	2.870″ / 72.90 mm
Bolt Size	M12 × 1.5
Bolt Hole MET	M10 × 1.25
