Overview

Wheel Hub 512207 supplied by DUHUI Bearing. Listed under Roller Bearings. Key published specifications: DH Code DWH1116; Product Type Wheel Hub Assembly; Installation Location Rear Axle, Right; Kit Contents Hub × 1. Contact the supplier through the RFQ form for pricing, lead time and full datasheets.

Technical specifications

DH Code	DWH1116
Product Type	Wheel Hub Assembly
Installation Location	Rear Axle, Right
Kit Contents	Hub × 1
Flange Diameter	5.984″ / 152.00 mm
Bolt Circle Diameter	4.500″ / 114.30 mm
Wheel Pilot Diameter	2.362″ / 60.00 mm
Brake Pilot Diameter	2.441″ / 62.00 mm
Flange Offset	2.933″ / 74.50 mm
Hub Pilot Diameter	2.913″ / 74.00 mm
Hub Bolt Circle Diameter	3.898″ / 99.00 mm
Bolt Size	M12 × 1.5
Bolt Hole MET	10.50 mm
Flange Shape	Offset Trapezoid
