Overview

Wheel Hub 512025 supplied by DUHUI Bearing. Listed under Roller Bearings. Key published specifications: DH Code DWH1024; Product Type Wheel Hub Assembly; Installation Location Rear Axle; Kit Contents Hub × 1. Contact the supplier through the RFQ form for pricing, lead time and full datasheets.

Technical specifications

DH Code	DWH1024
Product Type	Wheel Hub Assembly
Installation Location	Rear Axle
Kit Contents	Hub × 1
Flange Diameter	134.00 mm (5.280 inch)
Bolt Circle Diameter	100.00 mm (3.940 inch)
Wheel Pilot Diameter	52.00 mm (2.050 inch)
Brake Pilot Diameter	52.00 mm (2.050 inch)
Flange Offset	52.50 mm (2.070 inch)
Hub Pilot Diameter	62.20 mm (2.450 inch)
Bolt Size	M12 × 1.5
ABS Sensor	Without sensor (Non-ABS)
