Overview

Wheel Hub 512023 supplied by DUHUI Bearing. Listed under Roller Bearings. Key published specifications: DH Code DWH1022; Product Type Wheel Hub Assembly; Installation Location Rear Axle; Kit Contents Hub × 1. Contact the supplier through the RFQ form for pricing, lead time and full datasheets.

Technical specifications

DH Code	DWH1022
Product Type	Wheel Hub Assembly
Installation Location	Rear Axle
Kit Contents	Hub × 1
Flange Diameter	135.00 mm (5.310 inch)
Bolt Circle Diameter	100.00 mm (3.940 inch)
Wheel Pilot Diameter	56.90 mm (2.240 inch)
Brake Pilot Diameter	57.40 mm (2.260 inch)
Flange Offset	52.30 mm (2.060 inch)
Hub Pilot Diameter	70.10 mm (2.760 inch)
Bolt Size	M12 × 1.5
ABS Sensor	With integrated tone ring sensor
