Supply OEM/ODM Small Metal Lathe Ck1120 Swiss-Type CNC Lathe with 3 Axes
Overview
Supply OEM/ODM Small Metal Lathe Ck1120 Swiss-Type CNC Lathe with 3 Axes supplied by Dezhou Sanjia Machine Manufacturing Co., Ltd. Listed under Drilling Equipment. Key published specifications: Maximum diameter of boring hole Φ500mm; Maximum boring depth 1-16m (one size per meter); Spindle center height 630mm; Spindle speed range of the headstock 16～270r/min; Level 12. Contact the supplier through the RFQ form for pricing, lead time and full datasheets.
Technical specifications
| Maximum diameter of boring hole | Φ500mm |
|---|---|
| Maximum boring depth | 1-16m (one size per meter) |
| Spindle center height | 630mm |
| Spindle speed range of the headstock | 16～270r/min; Level 12 |
| Feed speed range | 0.5-450mm/min; stepless |
| Fast moving speed of pallet | 2m/min |
| Main motor power | 45KW |
| Drill pipe box motor power | 30KW |
| Hydraulic pump motor power | 1.5KW |
| Fast moving motor power | 5.5 KW |
| Feed motor power | 7.5KW |
| Cooling pump motor power | 5.5KWx3+7.5KWx1 (4 groups) |
| Rated pressure of cooling system | 2.5MPa |
| Cooling system flow | 100, 200, 300, 600L/min |
| Rated working pressure of hydraulic system | 6.3MPa |
| Z axis motor | 4KW |
| X axis motor | 23Nm (stepless speed regulation) |
