Supply OEM/ODM Cjl1-125 63A 30mA 4p Residual Current Circuit Breakers RCCB
Overview
Supply OEM/ODM Cjl1-125 63A 30mA 4p Residual Current Circuit Breakers RCCB supplied by PEOPLE ELECTRICAL APPLIANCE GROUP Co.,LTD. Listed under Switchgear. Key published specifications: Independent of line voltage Yes; Rated voltage Ue:(V) 230V or240V(1P+N):400V or 415V(3P+N); Rated current in:(A) 10A;16A;25A;20A;32A;40A;50A;63A;80A;100A;125A; Rated frequency:(Hz) 50/60Hz. Contact the supplier through the RFQ form for pricing, lead time and full datasheets.
Technical specifications
| Independent of line voltage | Yes |
|---|---|
| Rated voltage Ue:(V) | 230V or240V(1P+N):400V or 415V(3P+N) |
| Rated current in:(A) | 10A;16A;25A;20A;32A;40A;50A;63A;80A;100A;125A |
| Rated frequency:(Hz) | 50/60Hz |
| Rated residual operating current In:(A) | 30mA;100mA;300mA |
| Temporisation | Without time-delay |
| Total number of poles | 1P+N and 3P+N(neutral on left |
| Rated insulation voitage Ui:(V) | 415V |
| Rated impulse withstandvoltageUimp:(V) | 4000V |
| Utilisation rangetemperature:(°C) | -5°℃ to +40℃ |
| Rated making and breaking capacityIm:(A) | 10In for 63A:80A:100A:125A500A for 10A:16A:25A:20A:32A40A:50A |
| Short-circuit protection devices SCPDs used | Silver wire |
| Grid distance(short-circuit tests) | 50mm |
| Protection against external influences | Enclosed |
| Protection degree | IP20 |
| Material group | llla |
| Method of mounting | On rail |
| not associated with the mechanical-mounting | Yes |
| Type of terminals | Pillar terminal |
| Nominal diameter of thread:(mm) | 5.9mm |
| Operating means | Lever |
| Rated voltage Ue | (V) |
| Rated current in | (A) |
| Rated frequency | (Hz) |
| Rated residual operating current In | (A) |
| Rated insulation voitage Ui | (V) |
| Rated impulse withstandvoltageUimp | (V) |
| Utilisation rangetemperature | (°C) |
| Rated making and breaking capacityIm | (A) |
| Rated conditional short-circuit current Inc | (A) |
