Supply Cheap Aluminium Horizontal Slat Fence Panels and Automatic Sliding Gate supplied by Shenzhen Winfor Canbo Technology Co., Ltd. Listed under Proximity Sensors. Key published specifications: Power supply(wireless receiver) DC 12~30V; Static current 34mA(DC12V); Action current 62mA(DC12V); Main contact capacity（wireless receiver） 1A 24DV. Contact the supplier through the RFQ form for pricing, lead time and full datasheets.

Technical specifications

Power supply(wireless receiver)	DC 12~30V
Static current	34mA(DC12V)
Action current	62mA(DC12V)
Main contact capacity（wireless receiver）	1A 24DV
Power supply(Transmitter)	3V(2pcs 3V battery )
Standby current(Transmitter)	≤22μA(M mode) 40μA(K mode)
Emission current（Transmitter）	10mA
Touchless sensing distance	3-18cm
Infrared modulation frequency	38KHz
Infrared scanning interval	M mode: 330ms, K mode: 250ms
Receiver sensitivity	-95dbm
Emission distance	Over 30 meters in no obstacles area
Flush mounting version hole size(Transmitter)	53mm
Product size (Receiver)	64m(L)*12.4mm(W)
