SPDT DIN Rail Mount Phase Failure Relay
Model ATO-JVR
Overview
SPDT DIN Rail Mount Phase Failure Relay supplied by ATO Relays. Listed under Relays. Key published specifications: Measuring Circuit 3-Phase AC: L1, L2, L3; Voltage Unbalance Threshold 15% fixed; Delay Time for Undervoltage & Overvoltage 5-8s fixed; Reset Time 0.5s fixed. Contact the supplier through the RFQ form for pricing, lead time and full datasheets.
Technical specifications
| Measuring Circuit | 3-Phase AC: L1, L2, L3 |
|---|---|
| Voltage Unbalance Threshold | 15% fixed |
| Delay Time for Undervoltage & Overvoltage | 5-8s fixed |
| Reset Time | 0.5s fixed |
| Output Contacts | 1 C/O (SPDT or 1 Form C) |
| Contact Capacity | 3A, 250V AC (resistive load) |
| Degree of Protection | IP 20 |
| Humidity | ≤85%RH, non-condensing |
| Mechanical Durability | 1,000,000 cycles |
| Dielectric Strength | ＞2kVAC 1min |
| Mounting | 35mm DIN rail |
| Weight | 110g |
| Dimensions (H*W*D) | 68*30*76mm |
| 3-Phase AC | L1, L2, L3 |
| Dimension | (Unit: mm) |
