Rotary Paddle Type Material Level Switch For Tank
Overview
Rotary Paddle Type Material Level Switch For Tank supplied by Tianjin U-ideal Instrument Co., Ltd. Listed under Level Sensors. Key published specifications: Power supply 220VAC/110VAC/24VAC/24VDC; Contact capacity 250VAC/10A SPDT; Power 4W; blade rotation speed 1RPM. Contact the supplier through the RFQ form for pricing, lead time and full datasheets.
Technical specifications
| Power supply | 220VAC/110VAC/24VAC/24VDC |
|---|---|
| Contact capacity | 250VAC/10A SPDT |
| Power | 4W |
| blade rotation speed | 1RPM |
| Torque | 1.0kg×cm |
| Material Specific Gravity | ≥0.5g/cm³ |
| Working temperature | -10℃ -80℃; Maximum temperature 400℃ |
| Dielectric strength | 1500V*1min |
| IP Grade | IP65 |
| Blade Materia | SS304 |
| Power consumption | 5W |
| Blade speed | 1RPM |
| Voltage resistance | 1500VAC×1min |
| Working (medium) temperature of probe | Normal type: -20 ~ 50℃ |
| Inlet specification | 1/2 “PF |
| Protection level | IP65 |
| Material | 316 stainless steel |
| Installation | G2+1/2 “, 1+1/2 “, DN50 flange (customizable) |
