Premium Helical Gear Reducer AC Motor Unit Hardened Tooth Surface
Overview
Premium Helical Gear Reducer AC Motor Unit Hardened Tooth Surface supplied by Shanghai Fanbao Industrial Co., Ltd. Key published specifications: Output Torque 10-4890(N.M); Input Speed 1450rpm; Output Speed 0.12-397(rpm); Efficiency 94%~98%(depends on the transmission stage). Contact the supplier through the RFQ form for pricing, lead time and full datasheets.
Technical specifications
| Output Torque | 10-4890(N.M) |
|---|---|
| Input Speed | 1450rpm |
| Output Speed | 0.12-397(rpm) |
| Efficiency | 94%~98%(depends on the transmission stage) |
| Mounting Position | Foot, flange, torque, arm, hollow/s |
| Gearing Arrangement | Worm |
| Lubricating oil | GB L-CKC220-460, Shell Omala220-460 |
| Gear material | 20CrMnTi alloy steel |
| Surface hardness of gears | HRC58°~62° |
| Gear core hardness | HRC33~40 |
