Planetary Ball Mill with 0.1μm Output & Zirconium Balls
Model XQM-2
Overview
Planetary Ball Mill with 0.1μm Output & Zirconium Balls supplied by Guangzhou Zoli Technology Co.,Ltd. Key published specifications: Volume of each matched Jar 25-500ml; Voltage 220-240 v, 50/60 Hz; Motor power and frequency conversion power 1.1Kw; Machine Size 750×450×550mm. Contact the supplier through the RFQ form for pricing, lead time and full datasheets.
Technical specifications
| Volume of each matched Jar | 25-500ml |
|---|---|
| Voltage | 220-240 v, 50/60 Hz |
| Motor power and frequency conversion power | 1.1Kw |
| Machine Size | 750×450×550mm |
| Machine Weight | 120Kg without mill jar and balls |
| Mill mode | Dry / wet milling |
| Speed Frequency | Adjusting |
| Drive Mode | Gear drive |
| Rotate speed | Maximum orbital speed: 0-580r/min, Rotational speed: 0-1160r/min |
| Material Capacity | Material + mill balls < 2/3 volume |
| Output Granularity Size | Minimum 0.1μm |
| Max. continuous operating time (full-load) | 72 hours (Timer 0-9999h) |
| Interval operation | With direction reversal |
| Certification | ISO CEe |
| Grinding Ball Material | Zirconium Oxide |
| Grindingjarvolume | 250 Ml |
| Max Capacity | 500ml |
| Weight | 50 Kg |
| Power Consumption | 500W |
| Max Load Capacity | 4kg |
| Grinding Ball Weight | 1kg |
| Grinding Balls Size | 10 Mm |
| Powersupply | 220V/50Hz |
| Net Weight | 40 Kg |
| Dimensions | 450 X 350 X 400 Mm |
| Maximum orbital speed | 0-580r/min, Rotational speed: 0-1160r/min |
