Nickel 211 • N02211
Overview
AMETEK Inc in Shanghai lists Nickel 211 • N02211. Tensile strength 95,000 psi (655 MPa) maximum, yield strength 45,000 psi (310 MPa) maximum and elongation 30% minimum (in 2-inch gauge length) are among the specifications published.
Technical specifications
| Tensile Strength | 95,000 psi (655 MPa) maximum |
|---|---|
| Yield Strength | 45,000 psi (310 MPa) maximum |
| Elongation | 30% minimum (in 2-inch gauge length) |
| Hardness | HRB 80 maximum |
| Density | 0.315 lb/in³ |
| Melting Range | 2600°F (1427°F) |
| Thermal Conductivity | 342 BTU-in/ft2-h (at 68°F) |
| Electrical Resistivity | 40 μΩ-in (at 68°F) |
| Solution Temperature | Approximately 1600°F (871°C) |
| Modulus of Elasticity | 30 x 10^6 psi |
