LSB-450 Roll Feeding Square Bottom Paper Bag Making Machine
Overview
LSB-450 Roll Feeding Square Bottom Paper Bag Making Machine supplied by Ruian Lilin Machinery Co., LTD. Listed under Other Printing Machines. Key published specifications: Type LSB-450; Bag Width（W） 260-450 mm; Bottom Size（H） 85-180 mm; Bag tube length（C） 270-530 mm. Contact the supplier through the RFQ form for pricing, lead time and full datasheets.
Technical specifications
| Type | LSB-450 |
|---|---|
| Bag Width（W） | 260-450 mm |
| Bottom Size（H） | 85-180 mm |
| Bag tube length（C） | 270-530 mm |
| Bag Length（L） | L=C－(H÷2＋15~25) |
| Max.Speed | 180 pcs/min |
| Paper Thickness | 80-180 gsm |
| Paper Roll Width | 700-1250 mm |
| Max.Roll diameter | 1200 mm |
| Reel inner diameter | 76 mm |
| Total Power | 11 kw |
| Weight of Machine | 6200 kg |
| Overall Dimension(LxWxH) | 8250×2100×1800 mm |
