Latching Relay Part

Latching Relay Part

Overview

Latching Relay Part supplied by Apollo Electronic Components (Xiamen) Co.,Ltd. Listed under Relays. Key published specifications: Selling units Single item; Single gross weight 0.010 kg; Weight ( g ) ≈208g; Contact Arrangement 2A/2B. Contact the supplier through the RFQ form for pricing, lead time and full datasheets.

Technical specifications

Selling unitsSingle item
Single gross weight0.010 kg
Weight ( g )≈208g
Contact Arrangement2A/2B
Contact MaterialAgSnO2
Ambient Temperature-45~+85ºC
Vibration10~50Hz,0.75mm
Shock1000m/s²,(100g)
Power Consumption<1.5W
Operating Voltage16V
Max. Motor Voltage48V
Max. Switching Current200A
Surge Current3000A/10ms
Contact Voltage<60mV
Across Open Contact>2000VAC 1min
Electrical Life>10000cycles
Mechanical Life>100000cycles
Pulse Time100ms~150ms
Picking-up Time<65ms
Release Time<65ms
Insulation Resistance>1000MΩ(500VDC)
