Laser Engraving Machine
Model HB-6090D
Overview
Laser Engraving Machine supplied by Hibo (Liaocheng High-tech Zone) Trading Co., Ltd. Key published specifications: Processing Area 900mm*600mm; Laser Power 50W/60W/80W/100W/130W; Worktable Honeycomb or Blade; Engraving Speed 0mm-500mm/s Max. Contact the supplier through the RFQ form for pricing, lead time and full datasheets.
Technical specifications
| Processing Area | 900mm*600mm |
|---|---|
| Laser Power | 50W/60W/80W/100W/130W |
| Worktable | Honeycomb or Blade |
| Engraving Speed | 0mm-500mm/s Max |
| Cutting Speed | 60mm/s |
| Working Table Lifting Height | 200mm adjustable |
| Cutting thickness | 0mm-20mm(depends on materials) |
| Data Transfer Interface | USB/U Disk/Ethernet cable/WIFI(optional parts) |
| Minimum Shapping Character | Character:2mm*2mm, Leter: 1mm*1mm |
| Working Voltage | (220V or 110V±10% 50HZ/60HZ |
| Resetting Positioning | Accuracy less than or equal to 0.01mm |
| Graphic Format Supported | PLT/DXF/BMP/JPG/GIF/PGN/TIF |
| Operation Systerm | 2000XP/VISTA/Windoes 7/8/10 |
| Software | CoreIDRAW |
| Optional Parts | Rotary Axis, Water Chiller |
