H-ZSP7810
Overview
H-ZSP7810 supplied by OMCH. Listed under Photoelectric Sensors. Key published specifications: Output type Complementary output; The output voltage (V) V ≧Vcc-4; The frequency response(kHz) ≧50 (AC 500V 50/60Hz/min); Type Incremental. Contact the supplier through the RFQ form for pricing, lead time and full datasheets.
Technical specifications
| Output type | Complementary output |
|---|---|
| The output voltage (V) V | ≧Vcc-4 |
| The frequency response(kHz) | ≧50 (AC 500V 50/60Hz/min) |
| Type | Incremental |
| Outer diameter | 78mm |
| Shaft Diameter | 10mm |
| Outlet way | Cable side |
| Power supply voltage | 5V 5V~12V 12V~24V 24V |
| Cable length | Blank：Standard 2M |
| Zero position signal degree | M=zero signal |
| Out put signal | B=A,B, Z phase |
