Fully Automatic Rotary Disc Vacuum Filter Intelligent Discharge Ceramic Disc Filter
Overview
Fully Automatic Rotary Disc Vacuum Filter Intelligent Discharge Ceramic Disc Filter supplied by Jiangsu Ponis Environmental Technologies Co., Ltd. Key published specifications: Certification CE,UL; Filter Cloth Pore Size 10 Microns; Control Method Fully Automatic; Processing Flow 28~35m3/h (single Disk). Contact the supplier through the RFQ form for pricing, lead time and full datasheets.
Technical specifications
| Certification | CE,UL |
|---|---|
| Filter Cloth Pore Size | 10 Microns |
| Control Method | Fully Automatic |
| Processing Flow | 28~35m3/h (single Disk) |
| Filter Plate Diameter | 2000mm |
| Operating Hours | 24 Hours Continuous Operation |
| Filtration Area | 4.5m²/single disc |
| Filtration Rate | 8-15m/h/m² |
| Influent Water Quality | SS≤30mg/L |
| Outlet Water Quality | SS≤10mg/L |
| Filter Disc Material | Reinforced engineering plastic |
| Filter Cloth Material | Stainless steel, PE polyester |
| Body Material | Stainless steel |
| Backwash Drive Power | 1.5KW |
| Backwash Pump Power | 5-11KW |
| Washing Water Volume | 30L/1 tray/1 time |
| Cleaning Pressure | 6-8 bar |
| Head Loss | 50-200mm |
| Backwash Cycle | 1-3min (or continuous) |
| Working Pressure | Gravity filtration (or continuous) |
| Filtration Form | Cement tank type, box type |
