FM200 Fire Suppression
Overview
FM200 Fire Suppression supplied by FUJIAN HAIJING FIRE FIGHTING EQUIPMENT CO.,LTD. Listed under Fire Extinguishing Foam. Key published specifications: Filling Pressure（20℃） 2.5Mpa; Max. Working Pressure（50℃） 4.2Mpa; Standard GB16670-2006; Head Valve Driver Electromagnetic Drive or Electromagnetic/Pneumatic Drive. Contact the supplier through the RFQ form for pricing, lead time and full datasheets.
Technical specifications
| Filling Pressure（20℃） | 2.5Mpa |
|---|---|
| Max. Working Pressure（50℃） | 4.2Mpa |
| Standard | GB16670-2006 |
| Head Valve Driver | Electromagnetic Drive or Electromagnetic/Pneumatic Drive |
| Working Voltage and Current | DC24V, 1.3A |
| Maximum Single Protected Volume | 1600m³ |
| Discharge Time | ≤10s |
| Automatic Start Delay Time | 0-30s Adjustable |
